LED projector for wall and floor installation using dowels, suitable for lighting outdoor areas, gardens, parks and car parks. The optical compartment, the arm and the base are made of anodized aluminum alloy and subsequently powder coated to provide high resistance to atmospheric agents and UV rays, it acts as a radiating surface and guarantees excellent heat dissipation. The projector can be adjusted in the vertical plane by 90° by means of a painted steel bracket and provided with mechanical blocks which guarantee stable pointing of the light beam and 35° on the horizontal axis. Tempered extra-clear protective front glass (thickness 5mm) fixed by means of annealed silicone sealing gaskets to prevent the formation of deposits which would considerably reduce the performance of the appliance. Screws in stainless steel with a high molybdenum content. IP67 protection both on the product and on the cable using IP67 connectors.
Source
Chip On Board (COB) LED technology.
Optics
Rotosymmetrical optics available in various apertures (see datasheet) treated with high vacuum metallization and protected by a screen in tempered extra-clear safety glass.
Power supply
Electronic ballast integrated in the body of the fixture, available in the standard version (on-off). Power supply 220-240Vac 50/60Hz.
Note
We recommend the use of the SPD protection device, supplied by us upon request.
FAQ
Can it be placed outside?
The product can be installed outdoors, but it is necessary that the product and the connection system have an adequate IP protection rating.
