LED luminaire for recessed installation, using a spring system. Suitable for illuminating commercial and exhibition environments, where it is of fundamental importance to obtain high-performance lighting while preserving user comfort, the set back light source minimizes glare and allows for high visual comfort. Main body in die-cast aluminum, powder-coated, includes a radiant surface that guarantees optimal heat dissipation.
Source
LED Chip On Board (COB) technology 10W @ 500mA, 20W @ 700mA.
Optics
Roto-symmetrical high-definition optics (see table opposite) in metallized polycarbonate, integrated in the rear position in the black anti-glare screen.
Power supply
Electronic power supply supplied connected to the fixture, available in the standard (on-off) and dimmable (DALI) version. Power supply 220-240Vac 50 / 60Hz.
Note
Except for the black version, the stop frame is always in contrast with the anti-glare screen.
FAQ
Where should I place the remote power supply?
We recommend placing the power supply inside a grilled junction box to avoid overheating.
Can I connect multiple products to a single power supply?
During the estimate phase, the connection of one or more lighting fixtures to the power supply will be evaluated based on the arrangement in the room and the distance of the products from the driver. There are electronic power characteristics that must be evaluated by our technical office. Please request any information from your reference contact.
