LED projector for track installation. Body in aluminum profile, powder coated, with diameter 60mm and power 9W. Passive dissipation system through internal die-cast aluminum frame. Body adjustability from 0 ° to 90 ° on the vertical plane and 350 ° on the horizontal one, the aiming is blocked by friction. Variable optics (10 ° – 48 °) by means of an adjustment ring.
Source
LED Chip On Board (COB) technology.
Optics
Variable roto-symmetrical optic through adjustment ring (see table opposite) treated by high vacuum metallization and protected by a polycarbonate screen with satin “frost” effect designed to reduce glare.
Power supply
Electronic power supply integrated in the body of the fixture, available in standard (on-off) and dimmable (DALI) versions. Power supply via track 220-240Vac 50 / 60Hz.
Note
Track mount matching the projector body (white for the product with white finish and black for all the other colors).
Accessories
Electrified tracks (see appendix).
